Rack Airflow

Rack Airflow
Requirements

Requirements

Rack 10000 series Cabinets

The increasing power of new high-performance processor technology requires increased cooling
efficiency for rack-mounted servers. The 10000 Series Racks provide enhanced airflow for maximum
cooling, allowing these racks to be fully loaded with servers using the latest processors.

CAUTION:

CAUTION: If a third-party rack is used, observe the following additional requirements to ensure
adequate airflow and to prevent damage to the equipment:

Front and rear doors: If your 42U server rack includes closing front and rear doors, you
must allow 5,350 sq cm (830 square inches) of hole evenly distributed from top to bottom
to permit adequate airflow (equivalent to the required 64 percent open area for ventilation).
Side: The clearance between the installed rack component and the side panels of the rack
must be a minimum of 7 cm (2.75 inches).

CAUTION:

CAUTION: Always use blanking panels to fill all remaining empty front panel U-spaces in the rack. This
arrangement ensures proper airflow. Using a rack without blanking panels results in improper cooling
that can lead to thermal damage.

NOTE:

NOTE: For additional information, refer to the Setup and Installation Guide or the Documentation CD
provided with the server, or to the server documentation located in the Support section at the following
URL:

www.hp.com/servers/dl785

Rack Mounting

Rack Mounting
Requirements

Requirements

HP ProLiant DL785 G5 rack models provide tool-free support for racks with square or round mounting
holes (including Compaq/HP 7000, 9000, 10000, HP/E series, H9 series and third party racks) with an
adjustment range from 24" - 36" in depth. The ambidextrous cable management arm can be mounted
on either the left or right side for improved cable management.

HP ProLiant DL785 G5 in Telco Racks Support for all 2-post Telco racks requires the use of the standard
rack kit and an additional option kit from Rack Solutions (

http://www.racksolutions.com/hp/

)

Factory Express Portfolio

Factory Express Portfolio
for Servers and Storage

for Servers and Storage

HP Factory Express offers configuration, customization, integration and deployment services for HP
servers and storage products. Customers can choose how their factory solutions are built, tested,
integrated, shipped and deployed.

Factory Express offers service packages for simple configuration, racking, installation, complex
configuration and design services as well as individual factory services, such as image loading, asset
tagging, and custom packaging. HP products supported through Factory Express include a wide array of
servers and storage: HP Integrity, HP ProLiant, HP ProLiant Server Blades, HP BladeSystem, HP 9000
servers as well as the MSA1000, VA7xxx, EVA, XP, rackable tape libraries and configurable network
switches.

For more information on Factory Express services for your specific server model, please contact your
sales representative or go to:

http://www.hp.com/go/factory-express

HP Enterprise

HP Enterprise
Configurator

Configurator

The HP eCo-Enterprise Configurator now provides factory default racking for our HP hardware portfolio.
This approach is aligned with our strategic direction to meet the needs and expectations of our valued
customers. If you require "custom" rack configuration, please contact HP's Customer Business Center or
an Authorized Partner for assistance.

QuickSpecs

HP ProLiant DL785 Generation 5 (G5)

Standard Features

DA - 13046 Worldwide — Version 4 — May 21, 2008
