NOTE:

NOTE: This section lists some of the steps required to configure a Factory Integrated Model. To ensure only valid configurations are
ordered, HP recommends the use of an HP approved configurator. Contact your local sales representative for information on CTO
product offerings and requirements.
NOTE:

NOTE:

NOTE: HP does not allow factory integration of options into standard models listed above. Configure-to-order servers must start
with a CTO Chassis.
NOTE:

NOTE:

NOTE: This product offering does not support HP Factory Express Server Configuration Level 1.
NOTE:

NOTE:

NOTE: FIO indicates that this option only available as a Factory Installable Option.

Step 1: Base Configuration

Models

HP ProLiant DL785 G5 Rack CTO Chassis

AH233A

Factory Integrated Models ship with:

Two embedded NC371i Multifunction Gigabit Network Adapters
HP Smart Array P400i Controller
Integrated Lights-Out 2 (iLO 2) Standard management
Six (6) Redundant Hot Plug Fans
Three Hot Plug Power Supply
Rack 7U Form Factor

Step 2: Choose Required Options (only one of the following from each list unless otherwise

Step 2: Choose Required Options (only one of the following from each list unless otherwise
noted)

noted)

Processors

AMD Opteron™ 8354 2.2 GHz-2 MB Quad-Core Processor (75W) 4P Option Kit

NOTE:

NOTE: If eight processors are desired, select one 468121-L21 and one 468121-
B21.

468121-L21

AMD Opteron™ 8356 2.3 GHz-2 MB Quad-Core Processor (75W) 4P Option Kit

NOTE:

NOTE: If eight processors are desired, select one 468120-L21 and one 468120-
B21.

468120-L21

Base Memory

8 GB REG PC2-5300 (2 x 4 GB) Kit, dual rank

408854-B21

4 GB PC2-5300 DDR2 (2 x 2 GB) Kit, dual rank

408853-B21

2 GB PC2-5300 DDR2 (2 x 1 GB) Kit, single rank

408851-B21

NOTE:

NOTE: A minimum of two DIMMs (1 kit) must be installed per processor.
NOTE:

NOTE:

NOTE: Memory must be ordered in like-pairs, i.e. two of the same size.
NOTE:

NOTE:

NOTE: If all four banks on a memory node are populated, the maximum memory
clock speed will be 533 MHz. If two or fewer banks on a memory node are
populated, the maximum memory clock speed will be 667 MHz.

Storage Controllers

Storage Controllers
Upgrade Options

Upgrade Options

HP Smart Array P400 256MB FIO Cache

NOTE:

NOTE: Supports Smart Array P400 Controller and Smart Array P400i Controller only.

405139-B21

512MB Battery-backed write cache upgrade

405148-B21

QuickSpecs

HP ProLiant DL785 Generation 5 (G5)

Configuration Information - Factory Integrated Models

DA - 13046 Worldwide — Version 4 — May 21, 2008
