Page 20

4 Gb Fibre Channel

4 Gb Fibre Channel
HBAs

HBAs

HP StorageWorks FC2142SR HBA 4Gb PCI-e for Windows, Linux

A8002A

HP StorageWorks FC2242SR DC HBA 4Gb PCI-e for Windows, Linux

A8003A

Fibre Channel cables for

Fibre Channel cables for
2 Gb Infrastructure

2 Gb Infrastructure

Use 2 Gb Fibre Channel cables when connecting the MSA Fibre Channel I/O Module
to FCA2101 HBA(s)

2 m LC-LC Multi-Mode Fibre Channel Cable

221692-B21

5 m LC-LC Multi-Mode Fibre Channel Cable

221692-B22

15 m LC-LC Multi-Mode Fibre Channel Cable

221692-B23

30 m LC-LC Multi-Mode Fibre Channel Cable

221692-B26

50 m LC-LC Multi-Mode Fibre Channel Cable

221692-B27

Fibre Channel Cables for

Fibre Channel Cables for
1 Gb Fabric Switches and

1 Gb Fabric Switches and

1 Gb Fabric Switches and
Hub

Hub

Use 1 Gb Fibre Channel cables when connecting the MSA Fibre Channel I/O Module
and FCA2101 HBA(s) to 1 Gb Fabric Switches or hubs.

2 m LC-SC Multi-Mode Fibre Channel Cable

221691-B21

5 m LC-SC Multi-Mode Fibre Channel Cable

221691-B22

15 m LC-SC Multi-Mode Fibre Channel Cable

221691-B23

30 m LC-SC Multi-Mode Fibre Channel Cable

221691-B26

50 m LC-SC Multi-Mode Fibre Channel Cable

221691-B27

Step 5 – Choose Rack Options

Select each required option with quantities specified.

10647 (47U) Rack Cabinet - Pallet

245160-B21

10647 (47U) Rack Cabinet - Crated

245160-B23

10642 (42U) Rack Cabinet - Pallet

245161-B21

10642 (42U) Rack Cabinet - Shock Pallet

NOTE:

NOTE: It is mandatory to use a shock pallet in order to ship racks with equipment
installed

245161-B22

10642 (42U) Rack Cabinet - Crated

245161-B23

10636 (36U) Rack Cabinet - Pallet

245162-B21

10636 (36U) Rack Cabinet - Shock Pallet

NOTE:

NOTE: It is mandatory to use a shock pallet in order to ship racks with equipment
installed

245162-B22

10636 (36U) Rack Cabinet - Crated

245162-B23

10622 (22U) Rack Cabinet - Pallet

245163-B21

10622 (22U) Rack Cabinet - Shock Pallet

NOTE:

NOTE: It is mandatory to use a shock pallet in order to ship racks with equipment
installed.

245163-B22

10622 (22U) Rack Cabinet - Crated

245163-B23

S10614 (14U) Rack Cabinet - Shock Pallet

NOTE:

NOTE: It is mandatory to use a shock pallet in order to ship racks with equipment
installed.

292302-B22

10842 (800 mm wide, 42U) Rack Cabinet - Pallet

257415-B21

QuickSpecs

HP StorageWorks 1500 cs Modular Smart Array

Configuration Information

DA - 11945 Worldwide — Version 10 — September 26, 2005

Page 20
