Model Name

Contents' Description

Part Number

MSA1500 cs

MSA1500 controller shelf, 1-controller, 1- FC module, 1- SFP transceiver, 1- dual
channel SCSI I/O card, 2- power cables, redundant fans, redundant power supplies,
universal rack-mounting kit, MSA1500 support CD and documentation, serial cable.

NOTE:

NOTE: Fibre Channel cables, disk enclosures and hard drives are ordered separately.

AA986A

MSA1500 cs with one

MSA1500 cs with one
SATA drive enclosure

SATA drive enclosure

1- MSA1500 controller shelf base configuration, and 1-MSA20 SATA disk enclosure
base configuration.

NOTE:

NOTE: For Americas, Asia Pacific, and Japan.

AD509A

MSA1500 cs with one

MSA1500 cs with one
SCSI drive enclosure

SCSI drive enclosure

1- MSA1500 controller shelf base configuration, and 1-MSA30 single-channel SCSI
disk enclosure base configuration.

NOTE:

NOTE: For Americas, Asia Pacific, and Japan.

AD510A

MSA1500 SAN SCSI

MSA1500 SAN SCSI
Starter Kit

Starter Kit

(Windows, NetWare or Linux compatible)

NOTE:

NOTE: Includes (1) MSA1500 (1) MSA30 SCSI drive enclosure (1) 4/8 Base SAN
Switch (4) 4Gb SFP transceivers (2) FCA2214 HBAs + cables.

AE327A

MSA1500 SAN SATA

MSA1500 SAN SATA
Starter Kit

Starter Kit

(Windows, NetWare or Linux compatible)

NOTE:

NOTE: Includes (1) MSA1500 (1) MSA20 SATA drive enclosure (1) 4/8 Base SAN
Switch (4) 4Gb SFP transceivers (2) FCA2214 HBAs + cables.
NOTE:

NOTE:

NOTE: For Americas, Asia Pacific, and Japan only.

AE326A

MSA1500 SAN Starter Kit

MSA1500 SAN Starter Kit
HA Bundle

HA Bundle

HA Bundle
(for both SCSI and SATA
SAN Starter Kits)

(Windows, NetWare or Linux compatible)

NOTE:

NOTE: Includes (1) redundant controller; (1) FC I/O module; (1) 4/8 Base SAN
Switch (4) 4Gb SFP transceivers (2) FCA2214 HBAs + cables. User will need to
employ either Secure Path, QLogic failover, or Windows MPIO for path failover
implementation, not included. NetWare requires Secure Path.

AE328A

MSA1500 cs upgrade

MSA1500 cs upgrade
shelf

shelf

MSA1500 controller shelf, 1- dual channel SCSI I/O card, 2- power cables,
redundant fans, redundant power supplies, universal rack-mounting kit, MSA1500
support CD and documentation, serial cable.

AD511A

NOTE:

NOTE: This MSA1500 cs upgrade shelf does not include a controller or a Fibre
Channel I/O Module. It is intended for those customers who wish to upgrade from
their MSA1000 to the MSA1500 cs. For each controller added to this shelf, one Fibre
Channel I/O module (PN AA987A) is required.

NOTE:

NOTE: When upgrading to the MSA1500 cs, there is no space for the MSA1000
embedded switch or hub.

QuickSpecs

HP StorageWorks 1500 cs Modular Smart Array

Kit Contents

DA - 11945 Worldwide — Version 10 — September 26, 2005
