10 ©2009 Hunter Fan Co. 44827-01 20091015
figure 19.
High
Medium
Low
Off
figure 20.
figure 21.
operaTIon
To turn the fan on and off / control the speed. Turn the
speed knob on the top of the motor to the porper setting.
Figure 19.
off / speed selection
oscillation
To allow the fan to oscillate, push the Knob beside the fan
speed control down. Pull up on the knob if oscillation is
not desired. Figure 20.
adjustment
To adjust the angle the fan is blowing.
1. Loosen the adjustment knob under the Fan Motor
2. Adjust the fan to the angle desired and retighten the
knob to secure the fan at that angle. Figure 21.
