Hoshizaki DCM-750BWH(-OS) - Manual (Page 23)

23
H. Startup
WARNING
1. All parts are factory-adjusted. Improper adjustments may adversely affect
safety, performance, component life, and warranty coverage.
2. If the icemaker is turned off, wait for at least 3 minutes before restarting the
icemaker to prevent damage to the compressor.
3. At startup, confirm that all internal and external connections are free of leaks.
1) Open the water supply line shut-off valve(s).
2) Remove the front panel. Move the power switch to the "ON" position, then move the
control switch to the "OFF" position. See Fig. 7. Replace the front panel in its correct
position, then turn on the power supply.
Note: This unit will not run if the safety switch is not engaged.
3) Move the control switch to the "ICE" position to start the automatic icemaking process.
4) Once the unit starts to produce ice, allow it to run for another 30 minutes.
5) Move the control switch to the "DRAIN" position and allow the water system to drain for
5 minutes.
Note: If the unit is running, the drain valve will not open until 2.5 minutes after the
control switch is moved to the "DRAIN" position. This allows the components to
cycle down.
6) Move the dispense mode switch to the "CONTINUOUS" position and dispense all of the
ice from the storage bin.
7) Remove the front panel, then remove the storage bin cover.
8) To confirm bin control operation, move the control switch to the "ICE" position and
then engage the safety switch. Allow the unit to run until the compressor starts
(approximately 60 seconds). Press and hold the actuator paddle located inside the
storage bin.
WARNING! Keep hands, hair, and loose clothing clear of the agitator
inside the storage bin. The compressor should de-energize 90 seconds later, and the
gear motor should de-energize 60 seconds after that.
Fig. 7
Dispense Mode Switch
Control Switch
Power Switch
Safety Switch
Actuator Paddle
Storage Bin Cover
