Reviewing Video Clips
Document 900.0856 Rev 3.00 129
11/07
Note Image Processing works only in the single-screen layout and in
pause mode.
Note If you are not sure about the appropriate Video Format option,
try each option until the image displays properly.
• Click to select from Normal and Double screen views. Clicking the left
mouse button on the enlarged image moves its position.
• Click to display the image full screen.
• Encryption icons display in the bottom-right corner. indicates the clip file
has not been tampered with, and indicates the system has detected
tampering.
Note If the VGA card or monitor for your PC does not support 640x480
video resolution, Full Screen might not display properly when
selected. If this happens, press ESC on your PC to return to the
normal screen mode.
• Click the slider bar and move it left or right to move through the video clip.
• Placing the mouse cursor on an image and clicking it will cause that image to
display full frame.
