background image

MSA2000 Chassis

POWER REQUIREMENTS

Input Power
Requirements

110 VAC 3.6A/394W; 220VAC 1.9/385W

Max Input Power

100-240 VAC, 50/60 Hz., 4.5-1.9A; 48-60 VDC 10.4A/8.3A

Heat Dissipation

1622 BTU/hr

TEMPERATURE AND HUMIDITY RANGES

Operating Temperature

41°F to 104°F (5oC to 40°C)

Shipping Temperature

-40°F to 158°F (-40°C to 70°C)

Operating Humidity

10% to 90% RH @ 104°F (40°C) non-condensing

Non-Operating Humidity Up to 93% RH @ 104°F (40°C)

DECLARED ACOUSTIC NOISE LEVELS

Sound Power

< 6.5 Bels

Sound Pressure

< 57 dBA

SHOCK AND VIBRATION

Shock, Operational

5G's for 11 milliseconds, half sine

Shock, Non-Operational 15G 11ms half sine

Vibration, Operational

5-500Hz, 0.21Grms flat spectrum0.000089g2/HZ Random Vibration

Vibration, Non-
Operational

5-500-5Hz, 0.5 G peak to peak, sinusoidal

PHYSICAL

Height

3.436 in/ 8.727 cm

Depth (excluding cables)
(back of ear to back of
controller handle)

MSA2024: 20.28 in / 51.510 cm
MSA2012: 21.8 in. / 55.372 cm

Width (body only)

17.55 in / 44.58 cm (w/ ears 19 in / 48.26 cm)

Chassis Weight
(no controllers)

MSA2012 chassis: 44 lbs. MSA2024 chassis: 43 lbs

MSA2000sa G2
Controller

Host Interface

4 x4 lane SAS ports - 3Gb/s per lane

Protocol Support

SAS

RAID Support

0, 1, 3, 5, 6, 10, 50

Cache Memory

1GB Read/Write

Cache Backup

ECC protection with back up to flash memory ( indefinite backup)

Upgradeable Firmware yes

Disk Drive and
Enclosure Protocol
Support

3Gb SAS - Serial Attached SCSI / 3 Gb SATA II

Expansion Port

One 4X SAS connector (SFF8470) Expand up to 3 more drive
enclosures

QuickSpecs

HP StorageWorks 2000sa G2 Modular Smart Array

Technical Specifications

DA - 13331 Worldwide QuickSpecs — Version 2 — 7.31.2009
