2.16Port Monitoring
2.16.1 Port Monitoring commands - EXEC level
show mirror-port
Displays the configuration of the monitoring port.
Output Format:
Switch Configuration - Network Monitoring Port
Monitoring Enabled [No] : Yes
Monitoring Port : 3
Monitor : Ports
Port
Type
Action
| Port
Type
Action
----
-------- + -------
| ----
-------- + -------
3
10/100TX |
| 11
10/100TX |
4
10/100TX |
| 12
10/100TX |
5
10/100TX |
| 13
10/100TX |
6
10/100TX |
| 14
10/100TX |
7
10/100TX |
| 15
10/100TX |
8
10/100TX |
| 16
10/100TX |
9
10/100TX |
| Mesh Mesh
|
2.16.2 Port Monitoring commands - Configuration level
[no] mirror-port [<port-num>]
This command defines the switch port that will be used as the Monitoring Port for
diagnostic purposes. The switch ports that will be monitored are defined through the
monitor command at the Ethernet Interface Configuration Level. All the network
traffic seen by the monitored ports is copied to the Monitoring Port to which a
network analyzer can be attached.
Note: When monitoring multiple ports in a busy network, some frames may not be
copied to the monitoring port.
Parameters:
port-num - Port that will be acting as the monitoring port. A configured trunk port
cannot be used.
