iv Maintenance and Service Guide
Contents
5 Removal and Replacement Procedures
5.1 Serial Number . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–2
5.2 Disassembly Sequence Chart . . . . . . . . . . . . . . . . . . 5–3
5.3 Preparing the HP Notebook Expansion Base
for Disassembly. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–4
5.4 Base Plate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–5
5.5 Upper Chassis . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–6
5.6 Power Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–10
5.7 System Board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–12
5.8 Front Tray Cover. . . . . . . . . . . . . . . . . . . . . . . . . . . 5–14
5.9 Back Panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–16
5.10 Expansion Cable . . . . . . . . . . . . . . . . . . . . . . . . . . 5–17
5.11 Speaker Assembly. . . . . . . . . . . . . . . . . . . . . . . . . 5–18
5.12 Front Case . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–20
6 Specifications
A Connector Pin Assignments
B Power Cord Set Requirements
3-Conductor Power Cord Set . . . . . . . . . . . . . . . . . . . . . . B–1
General Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . B–1
Country-Specific Requirements . . . . . . . . . . . . . . . . . . . . B–2
C Screw Listing
Index
