Removal and Replacement Procedures
Maintenance and Service Guide 5–3
5.2 Disassembly Sequence Chart
Use the chart below to determine the section number to be
referenced when removing Expansion Base components.
Disassembly Sequence Chart
Section Description
# of Screws
Removed
5.3 Preparing the Expansion Base for disassembly
5.4 Base plate 4
5.5 Upper chassis 2
5.6 Power supply 5
5.7 System board 5
5.8 Front tray cover 4
5.9 Back panel 4
5.10 Expansion cable 4
5.11 Speaker assembly 2
5.12 Front case 6
