User’s Guide 3–12
Managing the Battery
Charging a Spare Battery
Battery Saving Tip: To ensure you always have battery power
available, invest in an extra Standard Battery or Extended
Battery. These batteries can be charged in the Desktop
Cradle. To purchase an extra battery, refer to the HP Web site
at
www.hp.com/products/pocketpc .
To charge an extra battery in the Desktop Cradle:
1. Plug the AC Adapter into an electrical outlet 1 and connect
the other end of the AC Adapter to the AC connector on the
desktop cradle 2.
2. Insert the battery into the battery compartment with the
connectors lined up on the lower right 3, and push the left
side of the battery into place 4.
3. When the Battery Light on the front of the Desktop Cradle 5
is amber, the battery is charging. When the light is green, the
battery is completely charged and ready to use.
Note: The stylus can be used to lift the left side of the battery to
remove it from the cradle.
