Integrated Serial ATA Integrated Serial ATA Integrated Serial ATA Integrated Serial ATA
Controller
Controller Controller Controller
Simultaneous drive Simultaneous drive Simultaneous drive Simultaneous drive
transfer channels
transfer channels transfer channels transfer channels
4 channels
Transfer rate synchronous Transfer rate synchronous Transfer rate synchronous Transfer rate synchronous
(maximum theoretical) 150 MB/s per channel; 300 MB/s in RAID 0 pair
Data transfer method Data transfer method Data transfer method Data transfer method Intel® 82801IR Integrated Serial ATA Host Controller (non-RAID mode)
Intel® 82801IR Integrated Serial ATA Host Controller (RAID Mode)
Drive support Drive support Drive support Drive support Serial ATA
Data transfer modes Data transfer modes Data transfer modes Data transfer modes Legacy Mode
Combined Mode
Protocol Protocol Protocol Protocol Serial ATA
Feature Feature Feature Feature NCQ (Native Command Queuing); AHCI (Advanced Host Controller
Interface)
RAID levels supported RAID levels supported RAID levels supported RAID levels supported 0, 1
RAID Features RAID Features RAID Features RAID Features Supports multiple logical volumes
Setup through ROM based Array Configuration Utility
Installation scripting support
NOTE: NOTE: NOTE: NOTE: This controller does not support Hot Plug functions or LED functions.
RAID OS Support RAID OS Support RAID OS Support RAID OS Support Microsoft Windows Server 2003
NOTE: NOTE: NOTE: NOTE: In order to implement integrated SATA RAID with Smart Start 7.90 on
Windows 2000/2003, the use of a floppy drive is necessary.
Linux (Red Hat, SuSE, UnitedLinux)
Embedded NC105i PCIe Embedded NC105i PCIe Embedded NC105i PCIe Embedded NC105i PCIe
Gigabit Server Adapter
Gigabit Server Adapter Gigabit Server Adapter Gigabit Server Adapter
Network Interface Network Interface Network Interface Network Interface 10Base-T/
100Base-TX/
1000Base-TX
Combines a triple-speed IEEE 802.3TM - Compliant Media Access
Controller (MAC) with a triple-speed Ethernet transceiver.
Compatibility Compatibility Compatibility Compatibility IEEE 802.3 10Base-T
IEEE 802.3ab 1000Base-T
IEEE 802.3u 100Base-TX
Data Transfer Method Data Transfer Method Data Transfer Method Data Transfer Method Four lane (x4), 100MHz PCI Express Reference Clock
Network Transfer Rate Network Transfer Rate Network Transfer Rate Network Transfer Rate 10Base-T (Half-Duplex) 10 Mb/s
10Base-T (Full-Duplex) 20 Mb/s
100Base-TX (Half-Duplex) 100 Mb/s
100Base-TX (Full-Duplex) 200 Mb/s
1000Base-TX (Half and
Full-Duplex)
2000Mb/s
Connector Connector Connector Connector RJ-45 connector
Cable Support Cable Support Cable Support Cable Support 10Base-T Categories 3, 4 or 5 UTP; up to 328 ft (100 m)
10/100/1000Base-TX Category 5 UTP; up to 328 ft (100 m)
QuickSpecs
HP ProLiant DL120 Generation 5 (G5) HP ProLiant DL120 Generation 5 (G5) HP ProLiant DL120 Generation 5 (G5) HP ProLiant DL120 Generation 5 (G5)
Technical Specifications
DA - 13014 North America — Version 6 — August 11, 2008 Page 27
