Heat & Glo • 6000G, 6000G-IPI • 2103-900 Rev. M • 9/08 9
MEASUREMENTS FROM
TOP EDGE OF THE OPENING
5
10
11
12
2-1/2
13
14
15
16
17
18
19
32
TO CEILING
9
10
11
12
8
7
6
5
4
3
25
18
A
To p V ie w
IN T E R IO R W A L L
F IR E P L A C E
O P E N IN G
B
M A N T E L L E G O R W A L L P R O J E C T IO N S
Note: All measurements in inches.
If A minimum is ____, then B maximum is_____.
A
Inches 2-7/16 3-7/16 4-7/16 5-7/16 6-7/16 7-7/16
Millimeters 62 87 113 138 164 189
B
Inches 1 2 3 4 5
∞
Millimeters 25 51 76 102 127
∞
Note: Measurement is taken from top of the
opening, NOT the top of the fi replace.
D. Mantel Projections
Figure 3.3 Clearances to mantels or other combustibles
above
appliance
Figure 3.4 Clearances to Mantel Legs or Wall Projections
(Acceptable on both sides of opening.)
