Heat & Glo • 6000G, 6000G-IPI • 2103-900 Rev. M • 9/08 20
IN S TA LL E D
H O R IZ O N TA L LY
4. Rear Vent - Vertical Termination
One Elbow
Figure 5.17
Two Elbows
Figure 5.18
V
1
Minimum H
1
Maximum
6 in. 152 mm 2 ft. 610 mm
1 ft. 305 mm 3 ft. 914 mm
2 ft. 610 mm 5 ft. 1.5 m
3 ft. 914 mm 7 ft. 2.1 m
4 ft. 1.2 m 8 ft 2.4 m
5 ft. 1.5 m 8 ft 2.4 m
V
1
+ H
1
= 40 ft (12.2 m) Maximum
H
1
= 8 ft (2.4 m) Maximum
H
1
+ H
2
Maximum V
1
Minimum
Back to Back 90° Elbows 3 ft. 914 mm
2 ft 610 mm 6 ft. 1.8 m
4 ft 1.2 m 9 ft. 2.7 m
6 ft. 1.8 m 12 ft. 3.7 m
8 ft. 2.4 m 15 ft. 4.6 m
V
1
+ H
1
= 40 ft (12.2 m) Maximum
H
1
+ H
2
= 8 ft (2.4 m) Maximum
