6 Quick Start Guide
CAUTION For proper airflow, the SFP media side of the FC 16B faces the
rear of the rack. This mounting allows air to enter from the front of the rack
and to exhaust at the rear of the rack, similar to other rack-mounted
equipment. This prevents switch overheating which may cause it to fail
To install the switch in a rack:
1. Check contents of the shipping carton to verify all the required parts and
hardware are available.
2. Choose a mounting location in the rack for the switch.
3. Attach the rear rail-tray brackets to the rear rack uprights by completing
one of the following steps:
– For an HP rack, install each of the two mounting brackets with (1)
M5 Torx head screw with captive lock washers as shown in Figure 2 .
Figure 2. Installing the Rear Rail-Tray Brackets (HP Rack-left rear upright))
