4. KM-1301SWH3 (water-cooled)
Note:
1. Pressure data is recorded at 5 minutes into freezing cycle. The data not in
bold
should be used for reference only.
2. We reserve the right to make changes in specifications and design without prior
notice.
70/21 1333 605 1323 600 1246 565
80/27 1326 601 1311 594 1198 544
90/32 1323 600 1300 590 1201 545
lbs./day kg./day 100/38 1286 584 1277 579 1110 503
70/21
80/27
90/32
watts 100/38
70/21 1414 5.35 1526 5.78 2036 7.71
80/27 1499 5.68 1673 6.33 2382 9.02
90/32 1526 5.78 1795 6.80 2431 9.20
gal./day m 3 /day 100/38 1846 6.99 1944 7.36 3015 11.41
70/21
80/27
90/32
min. 100/38
70/21
80/27
90/32
min. 100/38
70/21 237 16.7 238 16.7 249 17.5
80/27 238 16.7 239 16.8 256 18.0
90/32 238 16.7 240 16.9 255 17.9
PSIG kg/cm 2 G 100/38 244 17.1 244 17.1 269 18.9
70/21 50 3.5 50 3.5 52 3.7
80/27 50 3.5 49 3.5 53 3.7
90/32 50 3.5 49 3.4 52 3.7
PSIG kg/cm 2 G 100/38 51 3.6 50 3.5 55 3.9
17,400 BTU/h [AT 90ºF (32ºC) / WT 70ºF (21ºC)]
TOTAL HEAT OF REJECTION FROM COMPRESSOR 2,300 BTU/h [AT 90ºF (32ºC) / WT 70ºF (21ºC)]
WATER FLOW FOR CONDENSER 119 gal./h [AT 100ºF (38ºC) / WT 90ºF (32ºC)]
PRESSURE DROP OF COOLING WATER LINE less than 10 PSIG
