Page 15: Ii. general information a. construction
15
II. General Information
A. Construction
1. KM-1301SAH, KM-1301SAH3 (air-cooled)
Evaporator Assembly
Spray Tubes
Inlet Water Valve
Water Supply Inlet
Hot Gas Valve
Junction Box
Air-Cooled
Condenser
Check Valves
Control Box
Drier
Transformer Box
(KM-1301SAH3)
Control Switch
Bin Control Thermostat
Compressor
Cleaning Valve
Float Switch
Water Pump
Check Valve
(water)
Expansion Valves
Liquid Line Valve
Fan Motor
Fan Blade
Low-Side Service Valve
High-Side Service Valve
