Km-1301swh, km-1301swh3 (water-cooled) – Hoshizaki KM-1301SAH/3 User Manual
Page 16
16
2. KM-1301SWH, KM-1301SWH3 (water-cooled)
Evaporator Assembly
Spray Tubes
Inlet Water Valve
Water Supply Inlet
Hot Gas Valve
Junction Box
Water Regulating
Valve
Check Valves
Control Box
Liquid Line Valve
Drier
Transformer Box
(KM-1301SWH3)
Control Switch
Bin Control Thermostat
Compressor
Cleaning Valve
Float Switch
Water Pump
Check Valve
(water)
Expansion Valves
Water-Cooled
Condenser
Low-Side Service Valve
High-Side Service Valve
