English –
33
Adjusting the parking brake
The parking brake is adjusted as follows:
1. Loosen the locking nuts (1).
2. Tension the cable using the adjuster screw (2)
until the play in the cable is taken up.
3. Tighten the locking nuts (1).
4. The parking brake should be checked again
after the adjustment has been made.
WARNING!
A poorly adjusted parking brake
can result in reduced braking
ability and cause an accident.
6008-239H
MAINTENANCE
Adjusting the Parking Brake
Rider 155 AWD
Check that the parking brake is adjusted correctly
by placing the machine on a slope with the front
and rear axles disengaged. Apply and lock the
parking brake. When the machine does not stand
still, the parking brake should be adjusted accord-
ing to the following.
1. Remove the left-hand wing cover.
2. Loosen the locking nuts (1).
3. Tension the cable using the adjuster screw (2)
until the play in the cable is taken up.
4. Tighten the locking nuts (1).
5. The parking brake should be checked again
after the adjustment has been made.
6. Assemble the left-hand wing cover.
8009-501
6021-031
WARNING!
A poorly adjusted parking brake
can result in reduced braking ability
and cause an accident.
