22 Chapter 1
Installation Procedure
6. Verify Operation
6. Verify Operation
Verify proper operation of the HP-PB 100VG-AnyLAN Network Adapter
by checking the LEDs on the card. When the computer is switched on,
the Power LED will come on. At this point, the rest of the LEDs are in an
uninitialized state, and cannot be used until the driver on the system has
been started. After the driver has been started, the following Table 1-1,
may be used to interpret the LED patterns.
Table 1-1 LED Patterns
LED LED on LED off
Test Driver has detected a
fatal condition and is no
longer operating. Adapter is functioning
correctly.
10 Adapter is operating at
10Mbps. Adapter is not operating at
10Mbps.
100 Adapter is operating at
100Mbps. Adapter is not operating at
100Mbps.
Link Adapter is correctly
receiving a link signal
from the hub/switch. Adapter is not receiving a
link signal from the
hub/switch.
Activity Adapter is sending or
receiving a packet to/from
the hub/switch. No packet is currently being
transferred to/from the
hub/switch.
Power Adapter is receiving
power from the system. The system is not supplying
power, or the adapter is not
seated properly in the slot.
