Installation Procedure
3. Install the Adapter
2. Insert the adapter into the slot. Be sure the contacts and adapter
guides are properly aligned.
3. Fold in the extractor levers.
4. Press the adapter firmly until you feel the connector mate fully.
5. Secure the adapter in its slot by securing the retaining screws.
Figure 1-2
Inserting and Securing Adapter
d. Switch on the power to the computer.
1. Reconnect the source power supply to the computer.
2. Switch on the computer power switch.
