Removal and Replacement Procedures
Maintenance and Service Guide 5–33
5.13 Base Enclosure
1. Prepare the computer for disassembly ( Section 5.3 )
and remove the following components:
a. Hard drive ( Section 5.4 )
b. Optical drive ( Section 5.6 )
c. Memory module compartment cover ( Section 5.7 )
d. Mini PCI compartment cover ( Section 5.8 )
e. Keyboard cover ( Section 5.9 )
f. LED board ( Section 5.10 )
g. Keyboard ( Section 5.11 )
h. Display assembly ( Section 5.12 )
2. Position the computer with the front panel toward you.
Base Enclosure Spare Part Number Information
For use on HP Pavilion ze2300 models
For use on Compaq Presario M2300 models 395141-001
395142-001
