Chapter 8 List of Data Settings
8 - 9
Default
Code
Function name
Monitored data or setting
_FF _FEF _FUF
Setting
during
operation
(allowed
or not)
Change
during
operation
(allowed
or not)
Page
C001
Terminal [1] function (*2)
18
(*2)
¯
{
C002
Terminal [2] function
16
¯
{
C003
Terminal [3] function (*2)
06
(*2)
¯
{
C004
Terminal [4] function
11
¯
{
C005
Terminal [5] function
09
¯
{
C006
Terminal [6] function
03 03 13
¯
{
C007
Terminal [7] function
02
¯
{
C008
Terminal [8] function
01 (RV: Reverse RUN), 02 (CF1: Multispeed 1 setting), 03 (CF2: Multispeed 2
setting), 04 (CF3: Multispeed 3 setting), 05 (CF4: Multispeed 4 setting), 06 (JG:
Jogging), 07 (DB: external DC braking), 08 (SET: Set 2nd motor data), 09 (2CH:
2-stage acceleration/deceleration), 11 (FRS: free-run stop), 12 (EXT: external trip),
13 (USP: unattended start protection), 14: (CS: commercial power source enable),
15 (SFT: software lock), 16 (AT: analog input voltage/current select), 17 (SET3: 3rd
motor control), 18 (RS: reset), 20 (STA: starting by 3-wire input), 21 (STP: stopping
by 3-wire input), 22 (F/R: forward/reverse switching by 3-wire input), 23 (PID: PID
disable), 24 (PIDC: PID reset), 26 (CAS: control gain setting), 27 (UP: remote
control UP function), 28 (DWN: remote control DOWN function), 29 (DWN: remote
control data clearing), 31 (OPE: forcible operation), 32 (SF1: multispeed bit 1), 33
(SF2: multispeed bit 2), 34 (SF3: multispeed bit 3), 35 (SF4: multispeed bit 4), 36
(SF5: multispeed bit 5), 37 (SF6: multispeed bit 6), 38 (SF7: multispeed bit 7), 39
(OLR: overload restriction selection), 40 (TL: torque limit enable), 41 (TRQ1: torque
limit selection bit 1), 42 (TRQ2: torque limit selection bit 2), 43 (PPI: P/PI mode
selection), 44 (BOK: braking confirmation), 45 (ORT: orientation), 46 (LAC: LAD
cancellation), 47 (PCLR: clearance of position deviation), 48 (STAT: pulse train
position command input enable), 50 (ADD: trigger for frequency addition [A145]), 51
(F-TM: forcible-terminal operation), 52 (ATR: permission of torque command input),
53 (KHC: cumulative power clearance), 54 (SON: servo-on), 55 (FOC: forcing), 56
(MI1: general-purpose input 1), 57 (MI2: general-purpose input 2), 58 (MI3:
general-purpose input 3), 59 (MI4: general-purpose input 4), 60 (MI5:
general-purpose input 5), 61 (MI6: general-purpose input 6), 62 (MI7:
general-purpose input 7), 63 (MI8: general-purpose input 8), 65 (AHD: analog
command holding), 66 (CP1: multistage position settings selection 1 ), 67 (CP2:
multistage position settings selection 2), 68 (CP3: multistage position settings
selection 3), 69 (ORL: Zero-return limit function), 70 (ORG: Zero-return trigger
function), 71 (FOT: forward drive stop), 72 (ROT: reverse drive stop), 73 (SPD:
speed / position switching), 74 (PCNT: pulse counter), 75 (PCC: pulse counter
clear), no (NO: no assignment)
01
¯
{
4-46
C011
Terminal [1] active state
00 (NO) / 01 (NC)
00
¯
{
C012
Terminal [2] active state
00 (NO) / 01 (NC)
00
¯
{
C013
Terminal [3] active state
00 (NO) / 01 (NC)
00
¯
{
C014
Terminal [4] active state
00 (NO) / 01 (NC)
00
¯
{
C015
Terminal [5] active state
00 (NO) / 01 (NC)
00
¯
{
C016
Terminal [6] active state
00 (NO) / 01 (NC)
00
¯
{
C017
Terminal [7] active state
00 (NO) / 01 (NC)
00
¯
{
C018
Terminal [8] active state
00 (NO) / 01 (NC)
00
¯
{
In
te
lligent
input t
e
rm
inals
C019
Terminal [FW] active state
00 (NO) / 01 (NC)
00
¯
{
4-47
*2
When the emergency stop function is enabled (SW1 = ON), "18" (RS) and "64" (EMR) are forcibly written to parameters "C001" and "C003", respectively. (You cannot arbitrarily write "64" to
"C001".) If the SW1 signal is turned off and then turned on, "no" (no assignment) is set in parameter "C003".
