Attach pole assembly to tank assembly as shown. Secure pole assembly to
tank and wheel bracket by turning the pole assembly clockwise as shown.
Tighten pole completely and further rotate pole until struts are aligned
correctly as shown in FIG B.
5.
FIG B
TWO PEOPLE REQUIRED
FOR THIS PROCEDURE.
FAILURE TO FOLLOW THIS
WARNING COULD RESULT IN
SERIOUS INJURY AND/OR
PROPERTY DAMAGE.
WARNING!
IMPORTANT!:
The pole should be turned
approximately 7 complete
rotations to tighten properly.
When properly tightened, the
wheel bracket will be tight
against the base. An assistant is
recommended to hold the base
in place during this step.
