3-2. OPERATING CONTROLS (Continued)
Fig
.
No. Item No. Description Function
3-1 1 Radiant Heat A time proportioning controller, which means the higher
Infinite Regulator the number setting, the greater percentage of time the
Radiant heat will be on
3-1 2 Tubular Heat A time proportioning controller, which means the higher
Infinite Regulator the number setting, the greater percentage of time the
Tubular heat will be on
3-1 3 Light Fuse Holder A 15 amp protective device for the lighting circuit, that
must be replaced by a fuse of the same size and rating
3-1 4
Power Switch A two-position, three pole switch used to turn on and
off the heat control systems
3-2 5
Radiant Heater A long tubular heater mounted in a reflector located in
the ceiling panel of the unit
3-3 8
Lower Level A grid that sets in the lower level to prevent a bun pan
Pan Grid from dropping into the bottom of the unit when being lifted
out
3-4 9
Pan Support - Tilts the bun pans used in the top toward the customer
Top side of the unit
3-5 10
Light Bulb A 60 watt rated, long-life bulb that should be replaced
by the same wattage bulb
3-6 11
Lamp Socket A high temperature ceramic socket for holding the light
bulb
3-7
12 Tinted Glass Specially tempered colored glass with a thin film of
silicone that protects the light bulbs as well as color
the light
9
