HP BL685C User Manual
Page 31

Hardware options installation 31
11.
Remove the thermal interface protective cover from the heatsink.
IMPORTANT:
Do not install the air baffles on heatsinks for processors 3 and 4.
12.
If the heatsink will be installed on processor 1 or 2, expose the adhesive and apply the air baffles to
the side of the heatsink that will face the center of the server.
13.
Align the holes in the heatsink with the guide pins on the processor cage:
