Honeywell HREP4 - Manual (Page 48)

48
Installation
Configuring Audio Settings
1. Click AUDIO on the left side of the SOUND window.
2. Use the
to configure the following settings:
Configuring Buzzer Settings
1. Click BUZZER on the left side of the SOUND window.
2. Use the
to turn the keypad buzzer ON/OFF.
When the buzzer is on, each front panel button press is confirmed by a beep.
Configuring System Settings
Select SYSTEM in the Main system setup window, then click . The SYSTEM setup
window opens.
Figure 2-38 System Setup Window
LIVE AUDIO When ON, the selected audio channel can be monitored
on the AUDIO OUTPUT.
DEFAULT AUDIO
CHANNEL Specify which one of the four AUDIO INPUTS is routed to
the AUDIO OUTPUT.
NETWORK AUDIO TX When ON, live audio is transmitted to a remote PC
connection. Recorded audio is transmitted with video to a
remote PC for playback.
NETWORK AUDIO RX When ON, a remote PC connection can send audio back
to the DVR.
