46
Installation
Figure 2-34
SPOT OUT Menu
2. Click the camera channel to turn the monitor ON/OFF.
3. Double-click the spot-out channel that you want to assign. The Edit window appears.
Figure 2-35
SPOT-OUT Edit Window
4. Click
to bring up the virtual keyboard to change the Spot Title from DEFAULT. Use
the virtual keyboard to enter a name or reference number for the new sequence.
5. Turn the SCHEDULE ON or OFF.
6. Click MODIFY, then double-click the current display to modify it.
This window appears.
7. Click ADD. The Spot Sequence Setup window appears.
