IMPORTANT: THIS IS DATED INFORMATION. When requesting service or replacement
parts for your appliance please provide model number and serial number. All parts listed
in this manual may be ordered from an authorized dealer.
Stocked
at Depot
ITEM DESCRIPTION SERIAL # PART NUMBER
1 Transition Assembly 4059-044 N
2 Outer Transiton Assembly 24377 N
3 Inner Transiton Collar 4059-148 N
4 Damper Blade Assembly 4059-030 N
5 Damper Control 35159 N
6 Outside Air Collar Assembly Qty 2 req 4059-037 N
7 OA Door Qty 2 req 4059-049 N
8 Screen Rod Qty 2 req 4059-312 Y
Screen Rod Clips Qty 2 req 4059-111 N
9 Firescreen Assembly Qty 2 req 4059-028 Y
10 Grate Assembly GR29 N
11 Hearth Molded Brick Panel 4059-033 N
Traditional Molded Brick Panel
12 Lower Left Panel 4059-350 N
13 Upper Left Panel 4059-351 N
14 Lower Right Panel 4059-352 N
15 Upper Right Panel 4059-353 N
16 Lower Rear Panel 4059-354 N
17 Upper Rear Panel 4059-355 N
Herringbone Molded Brick Panel
18 Lower Left Panel 4059-357 N
19 Upper Left Panel 4059-358 N
20 Lower Right Panel 4059-359 N
21 Upper Right Panel 4059-360 N
22 Lower Rear Panel 4059-361 N
23 Upper Rear Panel 4059-362 N
Refractory Fastener Pack
4059-043 N
Contains:25 #6 X 1 1/2” Panhead screw, 3/32” Drill Bit, 17
T- Brackets, 2 Y-Brackets, 6 Clips,
Mortar 25 LB Box 4059-316 N
Outside Air Hood Qty 2 req 4059-051 N
Heatilator • Birmingham BIR42 • 4059-308 Rev E • 08/08
BIR42
Service Parts
