45
USEFUL INFORMA
TION
Features And Specifications
Supplied Accessories:
Remote Control •
Batteries (AAA) •
Owners Guide •
Easy Graphic Guide •
Stand Base •
Stand Screws •
Inputs/Outputs:
Wideband Component Y, Pb, Pr . . . . . . . . . . . . . . . . . . . . . . 1 •
Composite Video . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 •
Antenna (RF) Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 •
Audio Output. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 •
Optical Output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 •
HDMI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 •
USB Multimedia/SERVICE Slot . . . . . . . . . . . . . . . . . . . . . . . . . 1 •
RGB Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 •
RGB/DVI Audio Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 •
Phono Jack for Headphone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 •
Specifications:
FCC class . . . . . . . . . . . . . . . . . . . . . . . . . B for Consumer Use •
Power Requirements . . . . . . . . . . . . . . . . . . 108-132VAC, 60Hz •
1 Screen mode availability varies by input format.
VGA and XGA are trademarks of International Business Machines Corporation.
VESA is a registered trademark of the Video Electronics Standard Association.
HDTV Televisions display HDTV only when an HDTV source is available.
All specifications, weights, and dimensions are subject to change without prior notice.
Please access www.hitachi.us/tv for detailed specifications and dimensions for
custom installations.
Features:
New • High Gloss Black Frame
(4) HDMI •
® (V.1.3 with Deep Color, CEC)
1080p60, 1080p24 Input Compatible •
New • Multi-Function Remote Control
120Hz 1080p Perfected •
Reel 120 Motion Correction •
Dynamic/Standard/Movie/Custom/Game/Pro-Day/Pro-Night Picture •
Memories
3 Preset Color Temperatures
•
Game Mode •
Calibration Menu •
Video:
1920 x 1080p Display Resolution •
Wide Viewing Angle •
Color Temperature Presets: High, Medium, and Standard •
Multiple Screen Fill Modes: (Auto/4:3/16:9/Zoom1/Zoom2/Full) • 1
4MB 10-bit 3D Y/C Comb Filter •
Picture Modes: Dynamic/Standard/Movie/Custom/Game/Pro-Day/ •
Pro-Night
Audio:
CONEQ • TM Sound Quality
MTS Stereo/SAP •
4 Sound Modes (Custom, Standard, Movie, News) •
Rated Output Power: 5W+5W (L/R), 10W(Subwoofer) •
Inputs:
Power Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . AC 120V, 60Hz •
Power Consumption •
Maximum Power LE42S704 . . . . . . . . . . . . . . . . . 135 W, 1.20A
Maximum Power LE46S704 . . . . . . . . . . . . . . . . . 160 W, 1.35A
Antenna Input Impedance . . . . . . . . . . . . . . . . . . . . . . . . . . . 75 Ohm •
Channel Coverage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 191ch. •
VHF-Band . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2~13
UHF-Band . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14~69
CATV Mid Band . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A5~A1, A~I
Super Band . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . J~W
Hyper Band . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . W+1~W+28
Ultra Band . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . W+29~W+94
Television System . . . . . . . . . . . . . . . . . . . . . . . . . . . . NTSC Standard •
. . . . . . . . . . . . . . . . . . . ATSC Standard (8 VSB, 64-QAM, 256-QAM)
Video . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.0Vp-p, 75 Ohm •
S-Video •
Luminance(Y) . . . . . . . . . . . . . . . . . . . . . . . . 1.0Vp-p, 75 Ohm
Chrominance(C) . . . . . . . . . . . . . . . . . . . . . 0.286Vp-p, 75 Ohm
Component Video •
Luminance(Y) . . . . . . . . . . . . . . . . . . . . . . . . . 1.0Vp-p, 75 Ohm
Chrominance(Pb/Pr) . . . . . . . . . . . . . . . . . . . . . 0.7Vp-p, 75 Ohm
Audio Input Impedance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . >10k Ohm •
Audio Input Sensitivity. . . . . . . . . . . . . . . . . . . . . . . . . . . . 500mVrms •
HDMI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (19 PIN) •
TM
Manufactured under license from Real Sound Lab, SIA.
CONEQ is a trademark of Real Sound Lab, SIA.
CONEQ™ delivers clear, rich sound using proprietary
professional equalizing technology. Dialog is clear and music
sounds more dynamic when the speakers are perfectly
optimized.
CONEQ HA Mode™ (Hearing Aid) technology produces natural
sound for the hearing impaired. The listener can enjoy details in
music and clear dialog often without the help of a hearing aid.
CONEQ Surround™ is the 2-speaker Surround process (Stereo
Input and Output). This process provides natural surround
sound by widening the sound’s width, height and depth, while
maintaining high-fidelity, directionality and clear dialogue. In
terms of the technical aspects of this process, it has not only
the parameters for the surround but also the parameters to
enhance the center and the bass.
HDMI, the HDMI logo and High-Definition Multimedia Interface
are trademarks or registered trademarks of HDMI Licensing
LLC in the United States and other countries.
Manufactured under license from Dolby Laboratories. Dolby and
the double-D symbol are trademarks of Dolby Laboratories.
InstaPort and the InstaPort logo are tragemarks or registered
trademarks of Silicon Image, Inc. in the United States and other
countries.
