Hitachi LE46S704 - Manual (Page 33)

33
ON-SCREEN DISPLA
Y
Audio
Select Audio to adjust the sound to your preference.
Video Sound Mode Standard
Table Top
32
10
0
32 Bass
Treble
Balance
Bass Boost
CONEQ
Audio
Setup
Channels
Multimedia
Move
Adjust the sound to your preference.
Select SEL Return Exit EXIT
3D Sound CONEQ Surround
Sound Mode
This function has four sound modes that are preset according to
the type of program. Standard mode is for normal audio conditions,
Movie mode is for movies, News mode is for News programs, and
Custom mode is for adjusting audio levels to your preference. The
only mode that can be directly changed by adjusting any audio
setting to your desired conditions is the Custom mode. The other
modes are preset and any changes made to these modes will be
applied to Custom mode.
Audio Menu Settings Adjustment
Press the CURSOR PAD 1. or to select menu item.
Press the CURSOR PAD 2. or to adjust the function.
Press the EXIT button to quit the menu, or select Audio to 3.
return to the main menu.
If Treble is selected, you are adjusting treble. The
additional menu items Bass and Balance can be
selected and adjusted in the same manner.
Bass
This function controls the low frequency audio to the speakers.
Treble
This function controls the high frequency audio to the speakers.
Balance
This function will control the left to right balance of the LCD TV
internal speakers and headphone jack.
Bass Boost
This function enhances the depth of the sound from the TV
speakers.
CONEQ
Delivers clear crisp sound and high fidelity music playback. Use
the CURSOR PAD to select the preferred setting.
Table Top: Use this setting for improved sound quality with
table top stands.
Wall Mount: Select this setting for improved sound quality
when wall mounting.
Hearing Aid: This special mode is for users that want to
maintain clear sound after removing their conventional hearing
aid. Note that this feature emphasizes higher frequencies.
CONEQ Surround
Produces an impressive surround sound experience through the
TV’s sound system.
Audio Source
Multi-Channel Television Sound will allow you to select Stereo (a
stereo broadcast), Mono (monaural sound) used when receiving a
weak stereo broadcast or SAP(Second Audio Program) which may
be a secondary language, weather report, etc. This setting is only
for analog channels.
NOTE
Preferred Language
Some programs transmit in other languages. This language
function will allow you to set between 3 language options (English,
Español, and Français) to your preference as the audio default
language. This setting is only for digital channels.
Audio Language
Some programs transmit more than one DTV language option. Most
will have English as a default language. The language function will
allow you to select up to 6 language options (if available). Please
try all available options.
Digital Output
This function allows you to select between RAW and PCM. This
setting changes the format of the Digital Optical Output.
PCM: Select this feature if the TV is connected to an amplifier/
receiver with a PCM only decoder; it will provide two independent
soundtrack channels through the optical audio output jack (Digital
Audio).
RAW: Select this feature to allow the original audio bit stream
to be passed through to the audio receiver.
Internal Speakers
This function is useful when using external speakers. Select On if
using the internal speakers only. Select Off if you prefer to use the
speakers from a separate stereo system.
Perfect Volume
This function will automatically adjust volume so each channel and
input has the same average volume level.
Reset
This function allows you to reset the Audio Menu Settings of the
present input source and return it to the Standard mode and default
settings.
Video CONEQ Surround 3D Sound
On
Off
PCM
English
Unknown1
Preferred Language
Audio Language
Digital Output
Internal Speakers
Perfect Volume
Reset
Audio
Setup
Channels
Multimedia
Move
Reset all Audio settings to the original conditions.
Select SEL Return Exit EXIT
Use the CURSOR PAD 1. or to highlight functions.
Press the SELECT button or the CURSOR PAD 2. to select
Yes or No.
Press the SELECT button on the Yes option to execute the 3.
reset of the Audio settings.
Depending upon the audio program being heard, you can customize
each audio input to your preference to increase audio performance
and pleasure.
All the input sources will be reset to its initial condition by running
this Reset menu.
