Index–4 Maintenance and Service Guide
Index
headphone jack
location 1–9 , 1–11
pin assignments A–1
headset, spare part number
3–29 , 3–30
heat sink
removal 5–21
spare part number 3–9 ,
3–33 , 5–21
I
I/O address specifications
6–13
infrared port 1–7
interrupt specifications 6–11
K
keyboard
removal 5–30
spare part numbers 3–5 ,
3–31 , 3–32 , 3–33 , 3–34 ,
3–35 , 5–30
troubleshooting 2–26
keyboard components 1–16
keypad keys 1–17
L
LED board cable 3–25
left-side components 1–12 ,
1–14
M
mass storage devices, spare
part numbers 3–26
media cable, spare part number
3–29 , 3–30
memory map specifications
6–16
memory module
removal 5–15
spare part numbers 3–13 ,
3–37 , 5–15
memory module/Mini PCI
compartment cover
illustrated 3–23
location 1–25
removal 5–16
Memory Reader 1–15
Memory Reader light 1–15
microphone jack
location 1–9 , 1–11
pin assignments A–2
Mini PCI communications
module
removal 5–18
spare part numbers 3–13 ,
3–30 , 3–35 , 3–38
Miscellaneous Cable Kit
components 3–24
spare part number 3–24 ,
3–30
Miscellaneous Doors/Covers
Kit
components 3–22
spare part number 3–7 ,
3–22 , 3–30 , 3–34
modem board
removal 5–60
spare part number 3–7 ,
3–33 , 5–60
modem cable 3–25
