Removal and Replacement Procedures
Maintenance and Service Guide 5–3
5.2 Disassembly Sequence Chart
Use the chart below to determine the section number to
be referenced when removing computer components.
Disassembly Sequence Chart
Section Description # of Screws Removed
5.3 Preparing the Computer for
Disassembly
Battery pack 0
5.4 Hard Drive 2 loosened to remove the
hard drive cover
4 to remove the
hard drive frame
5.5 Computer Feet 0
5.6 Optical Drive 1
5.7 Memory Module 3 loosened to remove the
memory module/Mini PCI
compartment cover
5.8 Mini PCI Communications
Module 0
Å To prevent an unresponsive system and the display of a
warning message, install only a Mini PCI device authorized
for use in your computer by the governmental agency that
regulates wireless devices in your country. If you install a
device and then receive a warning message, remove the
device to restore computer functionality. Then contact
Customer Care.
5.9 RTC Battery 0
5.10 Heat Sink 1 loosened to remove the
thermal cover
4 removed to remove the heat
sink
