5–84 Maintenance and Service Guide
Removal and Replacement Procedures
5.22 USB Board
✎
This section applies to Compaq Presario V4200 and
HP Compaq nx7220 models. Refer to steps 11 through 18 in
Section 5.18, “System Board,” for instructions for removing
the USB board and frame on HP Pavilion dv4200 models.
1. Prepare the computer for disassembly ( Section 5.3 )
and remove the following components:
a. Hard drive ( Section 5.4 )
b. Switch cover ( Section 5.12 )
c. Keyboard ( Section 5.13 )
d. Display assembly ( Section 5.14 )
e. Top cover (HP Pavilion dv4200 models, Section 5.15 )
f. Base enclosure (Compaq Presario V4200 and HP Compaq
nx7220 models, Section 5.16 )
g. System board ( Section 5.18 )
2. Position the top cover with the left side toward you.
USB Board Spare Part Number Information
USB board (includes frame) 384625-001
