C–2 Maintenance and Service Guide
Screw Listing
Phillips PM2.0×5.0 Screw Locations
Table C-1
Phillips PM2.0×5.0 Screw
Color Qty. Length Thread
Head
Width
Black 6 5.0 mm 2.0 mm 5.0 mm
Where used:
1 Two screws that secure the hard drive cover to the computer (screws are
captured on the cover by C clips; documented in Section 5.4 )
2 Three screws that secure the memory module compartment cover to the
computer (screw is captured on the cover by C clips; documented in
Section 5.7 )
3 One screw that secures the thermal cover to the computer (screw is captured
on the cover by C clips; documented in Section 5.10 )
mm
