30
Title: E. Control Box Assembly Model: F-500BAF/-C
Index
No. Description
Material or
Model Number Part Number
Required Number
H-0
to
K-0
K-1
L-0 M-0
M-1
to
Q-0
1 Control Box GS 453691G01 1 -
4A2023G01 1 1 -
4A2023G02 1
2 Cover - Control Box GS 453692-01 1 1 1 1
Pan Head Screw w/Washer
(SW) 4×8, SS 7C1230408 2 2 2 2
3 Relay - Circuit Protect (X5) LY-1F-HSD,
240V 418271-05 1 1 1 1
4 Relay - Flush Valve Control
(X6) G2R-1-T,
AC24V 430173-03 1 1 1 1
5 Relay - Water Control (X3)
- Safety (X7) LY-2ZF, AC24V 406132-06 1 1 1 2
6 Tapping Screw - 431415-01 8 8 8 10
7 Transformer BE141625GEK 4A0557-01 1 1 1 1
8 Starter 3ARR3CT5M5 4A1107-11 1 1 1 1
T2 Screw 4×8 7P31-0408 1 1 1 1
9 Capacitor - Starting - 3A0076-10 1 1 1 1
10 Run Capacitor X386S(HG01) 439943-04 1 1 -
- 3A2005-08 1 1
11 Strap GS 434580-10 1 1 -
4A2262-02 1 1
T2 Screw 4×8 7P31-0408 1 1 1 1
12 Rocker Switch 62111929-0-
0-N 4A0558-01 2 2 2 2
13 Protector W28XQ1A-3,
3A 440972-02 1 -
14 Fuse AGC-1, 1A
250V 4A0893-01 1 1 1 1
15 Fuse Holder HTB921 4A0892-01 1 1 1 1
16 Timer Board H2AA144C01 437305-01 1 1 1 1
17 Board Support CBLS37-N 4A0336-03 4 4 4 4
18 Capacitor UP25B505UEF 443192-02 1 1 1 1
T2 Screw 4×8 7P31-0408 1 1 1 1
19 Relay - Gear Motor Protect (X4) LY-2F, AC120V 406132-07 1 1 1 1
20 Capacitor UP33B126UWPFSM,
12F 4A0894-01 1 1 1 1
T2 Screw 4×8 7P31-0408 1 1 1 1
21 9p Plug Housing 3191-09P-201 412832-02 1 1 1 1
22 6p Plug Housing 3191-06P-201 412832-03 2 2 2 2
23 4p Plug Housing 3191-04P-201 412832-05 1 1 1 1
24 Fuse Holder - 4A0892-02 1 1 1
25 Fuse - 4A0893-04 3 3 3
26 Lamp - 4A2672-01 1
27 2p Plug Housing - 412832-07 1
