Hoshizaki F-500BAF/-C User Manual

Page 15

background image

15

Title:

A. Ice Flaker Assembly Model: F-500BAF/-C

Index

No.

Description

Material or
Model Number Part Number

Required Number

H-0

J-0

J-1

K-0

K-1

to

M-0 M-1

N-0
P-0 P-1 Q-0

37

Stopper

SS

453670-01

1

1

1

1

1

1

1

T2 Screw

4×8

7P31-0408

1

1

1

1

1

1

1

38

Clamp

WS50-25-C

4A0337-01

1

1

1

1

1

1

1

39

Bracket – Evap (A)

-

4A2754-01

1

1

1

1

40

Bracket – Evap (B)

-

4A2755-01

1

1

1

1

41

Bracket – Evap (C)

-

3A2310-01

1

1

1

1

Hex Head Bolt w/Washer (LF)

5×10, SS

7B0230510

4

4

4

4
