Hoshizaki F-500BAF/-C - Manual (Page 13)

13
Title: A. Ice Flaker Assembly Model: F-500BAF/-C
Index
No. Description
Material or
Model Number Part Number
Required Number
H-0
J-0
J-1
K-0
K-1
to
M-0 M-1
N-0
P-0 P-1 Q-0
B Evaporator Assembly F-500BAF 339852A01 1 1 1 1 1 1 1
F-500BAF-C 339852A02 1 1 1 1 1 1 1
Socket Head Hex Bolt 8×95, SS 7S12-0895 3 3 3 3 3 3 3
Spring Washer M8, SS 7L22-0800 3 3 3 3 3 3 3
C Refrigeration Circuit - 108682A01 1 1 1 1 1 1 1
D Water Circuit Assembly - 108683A01 1 1 1 1 1 1 1
E Control Box Assembly - 227131A01 1 1 1 -
2A2486A01 1 1 1 1
Hex Head Bolt 4×8, SS 7B02-0408 1 1 1 1 1 1 1
F Cover Assy - Bin Top - 339855A01 1 1 -
3A1526A01 1 1 1 1 1
T2 Screw 4×8, SS 7P32-0408 7 7 7 7 7 7 7
G Sliding Door - 339858A01 1 1 1 1 1 1 1
H Label Location F-500BAF 227138A01 1 1 1 -
227138A03 1 1 1 1
F-500BAF-C 227138A02 1 1 1 -
227138A04 1 1 1 1
J Spout Assembly - 2A2511A01 See #8 below 1 1 1 1
1 Base GS 108681G01 1 1 1 1 1 1 -
1A1009G01 1
2 Frame (C) GS 227127G01 1 1 -
2A1948G01 1 -
2A1948G02 1 1 1 1
Truss Head Screw 4×8, SS 7C32-0408 7 7 7 7 7 7 7
3 Deflector (C) SS 453661G01 1 1 1 1 1 1 1
T2 Screw 4×8 7P31-0408 2 2 2 2 2 2 2
4 Side Frame (L) GS 227141G01 1 1 1 1 1 1 1
Truss Head Screw 4×8 7C31-0408 4 4 4 4 4 4 4
5 Drain Pan - 323765G01 1 1 1 1 1 1 1
6 Strap GS 453662-01 1 1 1 -
Truss Head Screw 4×8, SS 7C32-0408 2 2 2 -
7 Packing EPDM 427151-01 1 1 1 1 1 1 1
8 Spout - 227129-01 1 1 1 See Assy J
9 Spout Packing (A) EPDM 453663-01 1 1 1 1 1 1 1
10 Thumbscrew SS, ABS 415949G03 7 7 7 5 5 -
415949G11 5 5
11 Spout (B) ABS 227130-01 1 1 1 -
- 232654-01 1 1 1 1
12 Spout Packing (B) EPDM 453664-01 1 11 1 -
- 4A2769-01 1 1 1 1
13 Bin - Foamed - 108684G01 1 1 1 -
108684G02 1 1 1 1
T2 Screw 4×8 7P31-0408 1 1 1 1 1 1 1
Tooth Washer M4, SS 7R22-0400 1 1 1 1 1 1 1
T2 Screw 4×8, SS 7P32-0408 5 5 5 5 5 5 5
