Title: D. Water Circuit Assembly Model: F-500BAF/-C
Index
No. Description
Material or
Model Number Part Number
Required Number
H-0
J-0 J-1
K-0
K-1
L-0
to
Q-0
1 Water Valve Bracket GS 3A0553-01 1 1 1 1
T2 Screw 4×8 7P31-0408 3 3 3 3
2 Water Valve S-30 4A0865-01 1 1 1 1
T2 Screw 4×8 7P31-0408 2 2 2 2
3 Water Supply Pipe - 4A0891G01 1 1 1 1
T2 Screw 4×8 7P31-0408 2 2 2 2
4 Washer 4A0867-01 1 1 1 1
5 Reservoir - 2A0753-01 1 1 1 1
6 Reservoir Cover - 214810-01 1 1 1 1
7 Separator - Reservoir - 4A1255-01 1 1 1 1
8 Float Switch TW-1221-101 435490-01 1 1 1 1
9 Inlet - Reservoir - 4A0869-01 1 1 1 1
10 Water Valve S-60N 4A0866-01 1 1 -
- 4A2077-01 1 -
- 4A2772-01 1
T2 Screw 4×8 7P31-0408 2 2 2 2
11 Cover - Water Valve GS 453667-01 1 1 1 1
Truss Head Screw 4×8 7C31-0408 2 2 2 2
12 Fitting - 4A0776G01 1 1 1 1
T2 Screw 4×8 7P31-0408 2 2 2 2
13 Silicone Hose L=160 7730-0912 1 1 -
L=160 7730I3896 1 1
14 Silicone Hose L=200 7730-0912 1 1 -
L=190 7716-0913 1 1
15 Silicone Hose L=290 7730-1822 1 1 1 1
16 Reservoir Hose - 4A1165-02 1 1 1 1
17 Vinyl Hose L=360 7725-1923 1 1 1 1
18 Vinyl Hose L=715 7725-1923 1 1 1 1
19 Clamp SK-18.3 435934-06 1 -
20 Clamp MH-30N 421642-04 4 -
21 Cable Tie CV-150 7920-0003 7 2 2 2
22 Clamp SK-14 435934-02 1 -
23 Hose Clamp - 4A2017-01 3 3 3
24 Hose Clamp - 4A2017-02 1 1 1
25 Hose Clamp - 4A2017-04 4 -
4A2017-08 4 4
26 Hose Clamp - 4A2017-05 1 1 1
27 Hose Clamp - 4A2017-06 1 1 1
