B. Evaporator Assembly
F-500BAF-C
M-0, M-1, N-0, P-0, P-1, Q-0
Title: B. Evaporator Assembly Model: F-500BAF-C
Index
No. Description
Material or
Model Number Part Number
Required Number
H-0
to
J-1
M-0
to
P-1 Q-0
1 Gear Motor - 4A0897-02 1 -
4A2193-01 1 1
Hex Bolt GOLD STAIN-
LESS,
6×20 7B02-0620 4 -
Bolt 6×20 458660-01 4 4
Plain Washer SS, Ш6.4 Ч
Ш12.5 Ч t 1.6 7W22-0616 4 -
Spring Washer SS, 6 7L22-0600 4 -
2 Barrier - Gear Motor GS 3A1312-01 1 1 1
3 FT Screw 4×8, SS 7F32-0408 2 2 2
4 Coupling - Spline SS 418316-01 1 1 1
5 Housing - 206013G03 1 1 1
6 "O" Ring G40 7616-G040 1 1 1
7 Mechanical Seal HK9A-MS 22 432491-01 1 1 1
8 Ring (B) SS 432494-01 1 1 1
9 Auger SS 341448G01 1 1 1
10 Evaporator - 340076G01 1 -
2A1699G01 1 -
2A3310G01 1
Socket Head Cap Screw 6×10, SS 7S12-0610 4 4 4
Split Lock Washer M6, SS 7L22-0600 4 4 4
11 Extruding Head – 45N SS 327141G01 1 1 1
12 Cutter SS 440905-01 1 1 1
13 Washer SS 453791-01 3 3 3
14 Socket Head Cap Screw SS, M8Ч14 429121-01 3 3 3
