JPEG2000 Stand alone DVR User Guide
- 13 -
# 2
RxD
# 3
TxD
# 5
GND
TxD
# 3
GND
# 5
RxD
# 2
DVMR unit
Other device (PC)
D-SUB 9 cable (twisted RS-232C cable)
To connect DVR to a PC, users must use a twisted RS232 cable, as the illustration.
2-3-3 PTZ camera installation
Please connect the PTZ’s D+ to the DVR’s D+ , and D- to D-.
After the connection and the related setup is done, users are able to control the PTZ camera through the front
panel buttons. Please refer to Ch1and Ch6.
connector description
1
DCD
2
RxD
3
TxD
4
DTR
5
GND
6
DSR
7
RTS
8
CTS
9
NC
ASCII-CODE
Func. CODE Func. CODE Func. CODE Func. CODE Func. CODE
REC
R RIGHT
K MODE
D CH3 3 CH11
!
STOP
S NEXT
N PIP I CH4 4 CH12
@
PLAY
P ENTER
0X0D
SEQ
Q CH5 5 CH13
#
SEARCH
E - <
J.SHU
L
CH6
6
CH14
$
MENU
M + >
KLOCK
C
CH7
7
CH15
%
UP U PTZ
T
QPLAY
Y CH8 8
CH16
^
DOWN
J ZOOM
Z CH1
1 CH9 9
LEFT
H FRZ
F CH2
2 CH10 0
