Operating System (choice) Genuine Windows XP Professional (32-bit)
Genuine Windows XP Professional x64 Edition
Red Hat Enterprise Linux Workstation 4 Update 3.
HP Installer Kit for Linux 1 (includes drivers for both 32-bit & 64-bit OS versions)
(Tested and supported on Microsoft Windows 2000 Professional SP4. See HP White Paper at:
http://www.hp.com/workstations/white_papers/docs/xw4300_win2k_whitepaper_sept2005.pdf )
Form factor Minitower
Color Carbonite/Alloy metallic
Convertibility Yes. 5.25" drives rotate for Minitower or Desktop orientation.
System Board Form Factor ATX (9.6 x 12 in)
Processor
Single Intel Pentium 4 processors with Hyper-Threading Technology or Pentium D processors
CPU Bus Speed Supported 1066 and 800 MHz FSB
Standard L2 Cache
1 or 2 MB L2 cache, depending on specific processor
Chipset Intel 955X North bridge/ICH7R South bridge
Memory Expansion Slots 4 DIMMs
Memory Type Supported DDR2 (ECC and non-ECC)
Memory Speed Supported DDR2 SDRAM PC2-4300 (533 MHz) ECC
DDR2 SDRAM PC2-5300 (667 MHz) ECC
DDR2 SDRAM PC2-4300 (533 MHz) non-ECC
Maximum Memory 8 GB (4 DIMM slots)
Network controller Integrated Broadcom 5752 10/100/1000 for HP (PCI Express interface)
Audio Integrated High Definition digital audio with stereo microphone
PCI slots 3 PCI slots (full-height, full-length)
1 PCI Express x8 slot (x4 functionality)
1 PCI Express x1 slot
1 PCI Express x16 graphics slot
AGP slot None
Bays Total Bays = 6
Internal Bays Two 3.5 inch SATA Hard Drive
External Bays Three 5.25 inch bays
One 3.5 inch bay for optional floppy drive
Parallel Port 1
Serial Port 1 standard, 2nd is optional
Front I/O 2 USB 2.0, IEEE-1394 (requires optional PCI card to function), headphone and microphone.
NOTE: Although HP Personal Workstations can be ordered with the HP Installer Kit for Linux and an IEEE
1394 card, HP cannot provide customer support for this configuration. Please refer to the Linux Hardware
Support Matrix (
http://www.hp.com/support/linux_hardware_matrix ) for details, and to the Linux User
Manual ( http://www.hp.com/support/linux_user_manual ) for tips on user-enablement of the IEEE 1394
Card.
Rear I/O 6 USB 2.0, 1 standard serial port, 1 optional serial port, parallel port, PS/2 keyboard, PS/2 mouse, RJ-45,
audio in, audio out, mic in (audio/mic ports can be made function autosensing and interchangeably
retaskable by downloading a driver)
USB Keyboard Optional
USB Mouse Optional
PS/2 Keyboard 1
PS/2 Mouse 1
QuickSpecs
HP xw4300 Workstation
Standard Features - Specs
DA - 12260 Worldwide — Version 23 — May 25, 2007 Page 9
