HP XW4300 - Manual (Page 49)

System Requirements Disk Space 10 MB free disk space
Regulatory Approvals UL, cUL, EN 950, EN 60950, CSA, FCC, CE Mark, TUV, CISPR 22, EN 50082, IEC
1000 4-2, IEC 1000-4-3, AS/NZS, VCCI, BSMI, C-Tick
HP SpaceMouse Plus USB
(Windows XP only) Physical characteristics Dimensions (H x W x D) 7.4 x 4.72 x 1.73 in (18.8 x 12.0 x 4.4 cm)
Cap Diameter 2 x 6.5 x 6.6 mm
Weight 1.5 lb (0.68 kg)
Features Six degrees of freedom motion control through
the X, Y, Z axis (pitch, roll, yaw)
Certified for leading CAD and DCC applications
Environmental Operating temperature 41° to 140° F (5° to 60° C)
Non-operating
temperature -13° to 158° F (-25° to 70° C)
Operating humidity 10 to 98 % RH (non-condensing)
Non-operating humidity 10 to 98 % RH (non-condensing)
Mechanical Buttons 11 programmable (unshifted)
Cap Force Range 0.2 N – 4.5 N
Cap Torque Range 4 Nmm to 100 Nmm
Resolution 8 bit
USB Specifications Connector USB 1.1 or greater
Cable Length 6.56 ft (2 m)
Data Rate 16 msec
Software Drivers
Available Microsoft Windows XP Professional
System Requirements Disk Space 10 MB free disk space
Regulatory Approvals UL, cUL, EN 950, EN 60950, CSA, FCC, CE Mark, TUV, CISPR 22, EN 50082, IEC
1000 4-2, IEC 1000-4-3, AS/NZS, VCCI, BSMI, C-Tick
QuickSpecs
HP xw4300 Workstation
Technical Specifications - Input/Output Devices
DA - 12260 Worldwide — Version 23 — May 25, 2007 Page 49
