HP XW4300 - Manual (Page 44)

Short circuit detection (protects smart card and
reader)
Power supply compliant with ISO7816 and EMV
(5V, 60 mA)
Supports 3-V and 5-V cards
Power consumption 250-mA maximum draw (50 mA for the keyboard
with three LEDs ON and 200-mA maximum
startup current using a high-current, 60-mA smart
card)
Communication From card Programmable from
9,600 baud to 115,200
baud
From computer Up to 38,400 baud
Landing mechanism Contact device Friction contact
Card insertions rating Up to 100,000 insertion
cycles
Interface modes USB communications through USB port
SCM protocol
Automatic card insertion/removal detection
Reader performance
interface USB connection
Electro-magnetic
standards Europe 89/336/CEE guideline
USA USAFCC part 15
Operating system support Microsoft® Windows® 2000, Windows XP Home, Windows XP Professional,
xpe, ce.net, Linux, XP-64
Approvals CE-Mark, UL, CSA, FCC, CE Mark, TUV, TUV GS, VCCI, BSMI, C-Tick, MIC, JITC,
EMV2000, USB-IF
Ergonomic compliance ANSI HFS 100, ISO 9241-4, TUVGS
Kit contents Keyboard, I/O Security and Documentation CD, , warranty card
Smart card compatibility HP HP ProtectTools Smart Card
American Express Amex Blue
Axalto (Schlumberger) Cryptoflex 8K
Cryptoflex 16K
Cryptoflex 32K
Cryptoflex 32K e-gate
Cyberflex Access 64K
Cyberflex Access 32K
Cyberflex 32K e-gate
Cyberflex 64K
Cyberflex Palmera
Payflex-S
Payflex 1K
Payflex 2K
Payflex 4K
QuickSpecs
HP xw4300 Workstation
Technical Specifications - Input/Output Devices
DA - 12260 Worldwide — Version 23 — May 25, 2007 Page 44
