AISS Main Drive Ass'y (MDA) rework possible side-effects
Possible Failures After
Rework
Troubleshooting
Assembly
• PQ-defect (i.e.: wrong
color, Missing color
pane, process CPR)
• 54.XX Error
correct as instructed. (for details, see steps 16 and 17
above and re-check the MDA alignment as shown in
Figure 3 below)
For noise specifically, check the Cartridge Drum Sensors
on the MDA (see Figure 4)
59.C0 Error
One of the two drive gears on the engine is NOT correctly
inserted. Remove MDA and re-align gears as instructed
(see step 16 above)
