Multifunction
Networking The embedded multifunction NC373i combines standard Gigabit Ethernet networking, TCP/IP
offload engine (TOE) for Microsoft Windows and Linux iSCSI boot capability into a single adapter.
TOE moves the processing of data in the TCP protocol stack from the server CPU to the
network card, freeing CPU cycles for other activities. With TOE, network communications
are improved, and server efficiency is increased. The NC373i offers TOE for Microsoft®
Windows 2000 and 2003 environments.
The Linux iSCSI network boot (iSCSI boot) allows the BL460c to boot from a remote
operating system (OS) image located on a storage area network (SAN) within a Ref Hat or
SUSE Linux environment. The BL460c uses an iSCSI firmware image (iSCSI boot option
ROM) making the remote disk drive appear as a local, bootable C: drive. The BL460c is
configured to connect to and boot from the iSCSI target disk on the network and download
the OS image from the iSCSI target disk. The iSCSI boot option ROM is supplied by HP at
no cost. The additional cost and mezzanine slot usage of an add-in iSCSI HBA card is not
required. Additionally, the HP iSCSI boot solution includes scripts to significantly simplify the
installation process.
I/O Expansion Slots Two I/O expansion mezzanine slots (One x8 and one x4)
Integrated
Manageability Integrated Lights-Out 2 (iLO 2) Standard Blade Edition (integrated on motherboard)
Storage Controller HP Smart Array E200i
Controller 64 MB memory module supports RAID 0,1
Available upgrades: 128 MB with Battery-backed write cache
NOTE: For customers who choose to configure a driveless model via CTO, a storage controller is
not required. See Factory Integrated Models section for more information.
Maximum Internal
Storage Hot Plug Serial Attach
SCSI (SAS) 292 GB SAS 2 x 146 GB Serial SCSI
Hot Plug Serial ATA
(SATA) 240 GB SATA 2 x 120 GB Serial ATA
NOTE: For customers who choose to configure a driveless model via CTO, internal storage is not
required. See Factory Integrated Models section for more information.
Graphics Integrated ATI RN-50 1600x1280x64K 16M color (32 MB DDR1 memory)
Graphics Resolution
Supported Resolution Color Depths 1600 x 1280, 64K, 256, 16
1280 x 1024, 16.7M, 64k, 256.16
1024 x 768, 16.7M, 64k, 256,16
800 x 600, 16,7M, 64k, 256, 16
640 x 480, 16,7M, 64k, 256, 16
QuickSpecs
HP ProLiant BL460c Server Blade
Standard Features
DA - 12518 U.S. QuickSpecs — Version 27 — 5/12/2008 Page 6
