Page 70: 22 log/grate assembly
Heatilator • Caliber Mesh CD Series-SIT Valve • 4040-849 Rev J • 06/08
70
C. Service Parts
CD4236M Series
Service Parts
#
Description of Part
COMMENTS
CD4236MR
CD4236MLR
CD4236MIR
CD4236MILR
Qty
.
1
Flue Adapter
Plate
25882
25882
25882
25882
1
2
Flue Cover
34916
34916
34916
34916
1
3
Flue Adapter
Plate
w/Hole
4000-226
4000-226
4000-226
4000-226
1
4
Intake Collar
Assembly
4040-041
4040-041
4040-041
4040-041
1
5
Exhaust Collar
Assembly
4040-042
4040-042
4040-042
4040-042
1
6
Glass Clip Support
Assembly
33858
33858
33858
33858
4
7
Junction Box Radiation Shield
4031-193
4031-193
4031-193
4031-193
1
8
Junction Box (Plastic)
4021-013
4021-013
4021-013
4021-013
1
9
Junction Box Cover Plate
4031-222
4031-222
4031-222
4031-222
1
10
Flue Baf
fl e
4040-197
4040-197
4040-197
4040-197
1
11
Burner Pan
Assembly
4040-093
4040-093
4040-093
4040-093
1
12
Hearth Pan
4040-255
4040-255
4040-255
4040-255
1
13
Burner Support
4040-259
4040-259
4040-259
4040-259
1
14
Glass Heat Shield
4040-153
4040-153
4040-153
4040-153
1
15
Glass/Frame Assembly
4040-087
4040-087
4040-087
4040-087
1
16
Mesh Face
Assembly
4040-850
4040-850
4040-850
4040-850
1
17
Hood
4040-852
4040-852
4040-852
4040-852
1
18
To
p Latch Cover
4040-856
4040-856
4040-856
4040-856
1
19
Screen Assembly
4040-862
4040-862
4040-862
4040-862
1
20
Bottom Latch Cover
4040-858
4040-858
4040-858
4040-858
1
21
Floor Cover
4040-860
4040-860
4040-860
4040-860
1
Screen Rod
4040-866
4040-866
4040-866
4040-866
1
Grate Retainer
4040-272
4040-272
4040-272
4040-272
1
Glass Kit w/Screen
4040-033
4040-033
4040-033
4040-033
1
Screen Bracket
28159
28159
28159
28159
2
Back Refractory
4040-294
4040-294
4040-294
4040-294
1
22
Log/Grate Assembly
4040-051
4040-051
4040-051
4040-051
1
23
Front Y
Log
4040-200
4040-200
4040-200
4040-200
1
24
Front Log
4040-201
4040-201
4040-201
4040-201
1
To
p Log
Assembly
4040-038
4040-038
4040-038
4040-038
1
25
To
p Y
Log
4040-202
4040-202
4040-202
4040-202
1
26
To
p Log
4040-203
4040-203
4040-203
4040-203
1
27
Middle Log
Pre GA1647700
4040-206
4040-206
4040-206
4040-206
1
Post GA1647700
4000-316
4000-316
4000-316
4000-31
1
28
Back Log
Assembly
4040-207
4040-207
4040-207
4040-207
1
29
Gasket
4031-252
4031-252
4031-252
4031-252
1
30
V
alve Assembly
4040-061
4040-062
4040-063
4040-064
1
31
V
alve Plate Gasket
4040-198
4040-198
4040-198
4040-198
1
Lava Rock Bag
Assembly
4040-094
4040-094
4040-094
4040-094
1
Mineral W
ool
14333B
14333B
14333B
14333B
1
V
ermiculite (small)
28746
28746
28746
28746
1
Lava Rock (3lbs. Bag)
4021-297
4021-297
4021-297
4021-297
1
Caliber II Installation Instructions
4040-849
4040-849
4040-849
4040-849
1
1
17
16
15
14
31
12
13
11
9
7
6
5
4
3
2
10
8
19
20
18
21
29
30
#22 Log/Grate
Assembly
28
25
23
24
26
27
