Heatilator • Caliber Mesh CD Series-SIT Valve • 4040-849 Rev J • 06/08 62
16 16
Reference Materials
B
38-1/2 in.
(978 mm)
33-1/2 in.
(851 mm)
1-1/2 in.
(38 mm)
27-1/4 in.
(692 mm)
3 in.
(76 mm)
6-1/2 in.
(165 mm)
2-3/8 in.
(60 mm)
14-1/8 in.
(365 mm)
5-7/8 in.
(149 mm)
2 in.
(51 mm)
C
A
23 in.
(584 mm)
15-1/4 in.
(387 mm)
Gas Line
Access
Alternative
Gas Line
Access
Electrical
Access
38-1/4 in.
(972 mm)
A. Appliance Dimension Diagram
Dimensions are actual appliance dimensions. Use for reference only. For framing dimensions and clearances refer to Section 3.
Figure 16.1 Appliance Dimensions
Model # A B C
CD4236M in. 41 36 24
mm 1041 914 616
CD4842M in. 47 42 30
mm 1194 1067 768
