Heatilator • Caliber Mesh CD Series-SIT Valve • 4040-849 Rev J • 06/08 3
Safety Alert Key:
• DANGER! Indicates a hazardous situation which, if not avoided will result in death or serious injury.
• WARNING! Indicates a hazardous situation which, if not avoided could result in death or serious injury.
• CAUTION! Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury.
• NOTICE: Used to address practices not related to personal injury.
Table of Contents
A. Congratulations 2
B. Limited Lifetime Warranty 5
1 Listing and Code Approvals
A. Appliance Certifi cation 6
B. Tempered Glass Specifi cations 6
C. BTU Specifi cations 6
D. High Altitude Installations 6
E. Non-Combustible Materials Specifi cation 6
F. Combustible Materials Specifi cation 6
G. Requirements for the
Commonwealth of Massachusetts 7
User Guide
2 Operating Instructions
A. Gas Fireplace Safety 8
B. Your Fireplace 8
C. Fan Kit (optional) 9
D. Clear Space 9
E. Decorative Doors and Fronts 9
F. Fixed Glass Assembly 9
G. Remote Controls, Wall Controls and Wall Switches 9
H. Before Lighting Fireplace
9
I. Lighting Instructions (IPI) 10
J. Lighting Instructions (Standing Pilot) 11
K. After Fireplace is Lit 12
L. Frequently Asked Questions 12
3 Maintenance and Service
A. Maintenance Tasks-Homeowner 13
B. Maintenance Tasks-Qualifi ed Service Technician 14
Installer Guide
4 Getting Started
A. Typical Appliance System 15
B. Design and Installation Considerations 16
C. Tools and Supplies Needed 16
D. Inspect Appliance and Components 16
5 Framing and Clearances
A. Select Appliance Location 17
B. Construct the Appliance Chase 18
C. Clearances 18
D. Mantel and Wall Projections 19
6 Termination Locations
A. Vent Termination Minimum Clearances 20
7 Vent Information and Diagrams
A. Approved Pipe 22
B. Vent Table Key 22
C. Use of Elbows 22
D. Measuring Standards 22
E. Vent Diagrams 23
F. Install Vertical Termination Baffl e 32
8 Vent Clearances and Framing
A. Pipe Clearances to Combustibles 33
B. Wall Penetration Framing 33
C. Install the Ceiling Firestop 34
D. Install Attic Insulation Shield 35
9 Appliance Preparation
A. Convert from Top Vent to Rear Vent 36
B. Secure and Level the Appliance 40
10 Install Vent Pipe
A. Assemble Pipe Sections (DVP Only) 41
B. Assemble Vent Sections (SLP Only) 42
C. Assemble Slip Sections 42
D. Secure the Vent Sections 43
E. Disassemble Vent Sections 43
F. Install Decorative Ceiling Components (SLP only) 44
G. Install Metal Roof Flashing
45
H. Assemble and Install Storm Collar 45
I. Install RF4-8 46
J. Install Vertical Termination Cap 47
K. Install Decorative Wall Components (SLP only) 47
L. Heat Shield Requirements for
Horizontal
Termination 47
M. Install Horizontal Termination Cap 48
11 Gas Information
A. Fuel Conversion 49
B. Gas Pressure 49
C. Gas Connection 49
D. High Altitude Installations 49
12 Electrical Information
A. Wiring Requirements 50
B. Standing Pilot Ignition System Wiring 50
C. Intellifi re Ignition System Wiring 50
D. Optional Accessories Requirements 50
E. Electrical Service and Repair 51
F. Junction Box Installation 52
G. Wall Switch Installation for Fan (Optional) 52
13 Finishing
A. Mantel and Wall Projections 53
B. Facing Material 53
